XD-A
XDLASER
| Working area: | |
|---|---|
| Price range: | |
| Quantity: | |
| PDF Export | |
High Precision Engraving: Capable of intricate and precise engraving on non-metal surfaces like wood, acrylic, glass, leather, and more.
Adjustable Power and Speed: Allows customization of engraving depth, speed, and intensity based on the material and desired outcome.
6090 Working Area: Specifies the size of the engraving space - in this case, 600mm x 900mm - providing ample room for various project sizes.
Laser Source Options: Different wattage options for the laser source, providing flexibility in handling various materials and engraving depths.
User-Friendly Interface: Intuitive software interface for easy design import, manipulation, and execution of engraving tasks.
Compatibility: Capable of working with a wide range of design file formats, including vector-based formats like SVG, AI, DXF, etc.
Safety Features: Enclosed design with safety measures like emergency stop buttons, protective shields, and sensors to prevent accidents.
Cooling System: Efficient cooling system to maintain optimal laser performance during extended operation periods.
Rotary Attachment (Optional): Capability to add a rotary attachment for cylindrical object engraving, like bottles or cylindrical crafts.
Auto-Focus Functionality: Automates the focus adjustment process, ensuring precise engraving on materials with varying thicknesses.
Ventilation and Exhaust System: Integrated system for fume extraction to maintain a clean working environment and ensure user safety.
Remote Control and Connectivity: Options for remote control or connectivity, allowing monitoring or controlling operations from a distance.
More Information:
The Laser Engraving Machine Machinery 6090 is a CO2 laser cutter commonly used for non-metal materials. Here's some useful information about it:
Working area: The "6090" in the name refers to the working area, which is 600mm x 900mm (approximately 23.6 x 35.4 inches).
Material compatibility: It can engrave and cut a wide variety of non-metallic materials, including acrylic, wood, MDF, bamboo, leather, fabric, glass, and more. However, for materials like metal, ceramic, and thick glass, it can only engrave and may not be suitable for cutting.
Laser Power: These machines come in various laser power options, ranging from 40 watts to 150 watts. Higher wattage lasers can typically cut thicker materials or engrave at faster speeds.
Name: | XD-6040C 6090C 1390C |
Processing area | 600mm*400mm,900mm*600mm,1300mm*900mm |
Laser power | 60W,80W,100W,150W |
Laser type: | Co2 glass laser tube |
Software: | Laser work V6 |
Dimension: | 1950mm*1800mm*1150mm |
Cutting speed | 1-600mm/s, cutting acrylic 10mm thick: 10-15mm/s |
Cutting thickness | Acrylic up to 25mm,MDF up to 12 mm |
Resolution ratio | ≤0.0125mm |
Position system: | Red light position system |
Interface: | USB |
Minimum shaping character | letter 0.5mm, Chinese 0.5 mm |
Support graphic format | DST, PLT, BMP, DXF |
Gross power | 1000W |
Driving mode: | DC0.8A 24V stepper motor |
Cooling mode: | Circulation water cooling |
Working voltage: | AC220V/50HZ or 110V/60HZ or depend on customer |
Operating temperature | 0-45C |
Operating humidity: | 5-95% |
Operation: | Video to tell customer how to operate the machine |
XDLASER offer whole life free technical support for every laser machine you buy, welcome you to contact XDLASER for details.
info@xdlasers.com
Whatsapp: +86-15169026664
Its time to contact us and get a quotation:
info@xdlasers.com
Whatsapp/wechat: +86-15169026664
Skype: juliali01
High Precision Engraving: Capable of intricate and precise engraving on non-metal surfaces like wood, acrylic, glass, leather, and more.
Adjustable Power and Speed: Allows customization of engraving depth, speed, and intensity based on the material and desired outcome.
6090 Working Area: Specifies the size of the engraving space - in this case, 600mm x 900mm - providing ample room for various project sizes.
Laser Source Options: Different wattage options for the laser source, providing flexibility in handling various materials and engraving depths.
User-Friendly Interface: Intuitive software interface for easy design import, manipulation, and execution of engraving tasks.
Compatibility: Capable of working with a wide range of design file formats, including vector-based formats like SVG, AI, DXF, etc.
Safety Features: Enclosed design with safety measures like emergency stop buttons, protective shields, and sensors to prevent accidents.
Cooling System: Efficient cooling system to maintain optimal laser performance during extended operation periods.
Rotary Attachment (Optional): Capability to add a rotary attachment for cylindrical object engraving, like bottles or cylindrical crafts.
Auto-Focus Functionality: Automates the focus adjustment process, ensuring precise engraving on materials with varying thicknesses.
Ventilation and Exhaust System: Integrated system for fume extraction to maintain a clean working environment and ensure user safety.
Remote Control and Connectivity: Options for remote control or connectivity, allowing monitoring or controlling operations from a distance.
More Information:
The Laser Engraving Machine Machinery 6090 is a CO2 laser cutter commonly used for non-metal materials. Here's some useful information about it:
Working area: The "6090" in the name refers to the working area, which is 600mm x 900mm (approximately 23.6 x 35.4 inches).
Material compatibility: It can engrave and cut a wide variety of non-metallic materials, including acrylic, wood, MDF, bamboo, leather, fabric, glass, and more. However, for materials like metal, ceramic, and thick glass, it can only engrave and may not be suitable for cutting.
Laser Power: These machines come in various laser power options, ranging from 40 watts to 150 watts. Higher wattage lasers can typically cut thicker materials or engrave at faster speeds.
Name: | XD-6040C 6090C 1390C |
Processing area | 600mm*400mm,900mm*600mm,1300mm*900mm |
Laser power | 60W,80W,100W,150W |
Laser type: | Co2 glass laser tube |
Software: | Laser work V6 |
Dimension: | 1950mm*1800mm*1150mm |
Cutting speed | 1-600mm/s, cutting acrylic 10mm thick: 10-15mm/s |
Cutting thickness | Acrylic up to 25mm,MDF up to 12 mm |
Resolution ratio | ≤0.0125mm |
Position system: | Red light position system |
Interface: | USB |
Minimum shaping character | letter 0.5mm, Chinese 0.5 mm |
Support graphic format | DST, PLT, BMP, DXF |
Gross power | 1000W |
Driving mode: | DC0.8A 24V stepper motor |
Cooling mode: | Circulation water cooling |
Working voltage: | AC220V/50HZ or 110V/60HZ or depend on customer |
Operating temperature | 0-45C |
Operating humidity: | 5-95% |
Operation: | Video to tell customer how to operate the machine |
XDLASER offer whole life free technical support for every laser machine you buy, welcome you to contact XDLASER for details.
